Page 90 - Road Show

A-19334
Back Panel Assembly
Item Part Number Description
A-19298.2 Back Panel
2 A-18948 Rear DiverterAssembly
A) A-19333 Rear Diverter Bracket
B) A-18949 Diverter BladeAssembly
C) 20-8790 Nyliner Bearing
D) 03-7066 Coil Tubing
E) 01-8413 Coil Mounting Bracket
F) AE-26-1200 Coil Assembly
G) A-12390 Flipper Stop Assembly
H) 10-437 Spring
J) A-13278 Plunger Assembly
K) A-19293 Drive Arm Assembly
M) 20-8712-25 "E"-R ing 1/4"Shaft
N) 4010-01082-04 Mach. Screw, 10-32 x 1/4"
P) 4010-01008-06 Mach. Screw, 10-32 x 3/8"
RfO-WHT
@
BACK VIEW
I
FRONT VIEW :
I
I
,-------------L-- ---------- l
I I
I I
I I
I I
I I
I I
I I
I I
I I
I I
I I
I I
L J
Item Part Number Description
3 24-8802 Bulb #906 13v, 0.69A
4 A-14265-13 Receptacle& Socket (Clear)
5 03-8171-13 Mini DomeTwist/lock (Clear)
6 03-8171-16 Mini Dome Twist/lock (Yellow)
7 03-8171-9 Mini Dome Twist flock (Red)
8 4700-00003-00 Flatwasher, .125 x .281 x .032
9 H-19602 Back Panel Cable
10 4408-01119-00 Nut 8-32 ESN
11 07-6688-19 Rivet, 1/8 x 7/32" Nickel
