Page 89 - Road Show

A-19046
Loop Assembly
,
,,
I
I
I
I
I
I
I
I
I'.,,
\\'"
" ,
...•...•...•
r-- ---- - ---,
I I
I I
I I
I I
I I
I ,
[ i i: ~~~~~~~~~~~~1r~~~--r~;
~ : I Illt~~ \~ r I
~I I I "d~ II \I. \I I I
~ L···=·=-----Jil}-~-_,_.-~ t
___ I_!: : IU l_J
Item Part Number Description
1 A-19327 Loop Sub-Assembly
2 AE-23-800 Coil Assembly
3 03-7067 Coil Tubing
4 10-135 Spring Plunger
5 23-6420 Grommet
6 01-9784 Coil Mounting Bracket
7 A-17767 Bell Armature Assembly
8 4408-01119-00 Nut 8-32 ESN
9 5647-12693-20 Mini-Micro Switch
10 01-8600 Insulator
11 01-8240 Nut Plate, #2-56
12 4002-01105-07 Mach. Screw, 2-56 x 7/16"
13 5070-09054-00 Diode 1N4004
14 H-19523 Mini Switch Cable
15 H-16437 Radio Cable
2-31
