Flipper Assembly
A-15849-L-4
Flipper Assembly
(Parts listed replace same items of A-15849-L-1)
(Parts listed replace same items of A-15849-L-1)
Item Part Number
Description
~ Part Number
Description
12 FL-11722
Flipper Coil, Green
12 FL-15411
Flipper Coil, Orange
Associated Parts:
21 23-6553-4
22 20-9264-6
Small Flipper Rubber Ring, Red
Small Flipper & Shaft
A-15849-R-4
Flipper Assembly
Item Part Number
Description
.!Wn
Part Number
Description
1 A-13104-R
Flipper Bracket Sub-Assy.
18 A-15848-R Crank Link ASsembly, Right
2 SW-1A-194
Switch Assembly
a)
A-17050-R Flipper Crank Assembly, Right
3 4701-00002-00 Lockwasher, #6 Split
b)
A-15847
Flipper Link Assembly
4 4105-01019-10 Sh. Metal Screw, #5 x 5/8"
c)
02-4676
Link Spacer Bushing
5 4008-01079-05 Mach. Screw, 8-32 x 5/16"
d)
4010·01086-14 Cap Screw, 10-32 x 7/8"
6 4701-00003-00 Lockwasher #8 Split
e)
4700-00023-00 Flatwasher, 5/8 x 13/64 x 16ga.
7 01-9375
Switch Mounting Bracket
f)
4701-00004-00 Lockwasher #10 Split
8 20-6516
Speednut, Tinnerman
g)
4410-01132-00 Nut, 10-32 ESN
9 4010-01066-06 Cap Screw, 10-32 x
318"
19 23-6577
Bumper Plug, 5/8"
10 4701-00004-00 Lockwasher #10 Split
20 03-7568
Flipper Bushing
11 A-12390
Flipper Stop Assembly
12 FL-15411
Flipper Coil, Orange
a) 03-7066-5
Coil Tubing
Associated Parts:
13 01-7695
Solenoid Bracket
(Not Shown)
14 4006-01017 -04 Mach. Screw, 6·32 x 1/4"
15 10-364
Spring
21 23-6519-4
Flipper Rubber Ring, Red
16 4006-01005-06 Mach. Screw, 6-32 x 3/8"
22 20-9250-6
Flipper & Shaft
17 4406-01117-00 Nut, 6-32 Hex
Flipper Notes ...
1. Each Flipper Assembly is mounted beneath the playfield, in conjuction with the Plastic Flipper & Shaft,
and Flipper Rubber on the upper side of the playfield.
2. With the flipper, in the non-activatedposition, the E.O.S. Switch contacts must have a gap of .062
(±.OlS)
inch.
When flipper is activated switch must close.
3. Any adjustment of the E.O.S. switch must be made at a minimum distance of 0.25 inch from the switch body.
4. Longer blade of E.O.S. switch must be made straight. Gap adjustment is done by adjusting shorter blade.
5. All moving elements of the assemblymust operate freely without any evidence of binding.
6. Apply Loctite™ 245 when reatachingscrews to the Flipper Stop Assembly, the Solenoid Bracket,
and the Flipper Bushing.
