Flipper Assembly
pIn
C-9952-L
(Parts listed replace same Items of C-9952-R)
Item Part No.
Description
1 B-10655-L
g) B-10657-L
1.) 01-8073-L
2 C-9954-L
Crank Link Assembly
Flipper Crank Assembly, Left
Flipper Crank, Left
Flipper Base/Lane Change Assy, L.
Road Kings
Y-Ramp
pIn
C-11135
Item Part No.
Description
1
2
3
4
5
6
7
03-8021
01-8388
02-4266
10-391
4006-01003-06
4700-00009-00
03-8042
Y-Ramp, Plastic
Ramp Lane Selector
Lane Selector Mounting Post
Selector Spring
Mach. Screw 6-32 x 3/16, P-PH-S
Flat Washer, #6
Nylon Washer
Flipper Assembly
pIn C-99S2-R
Item Part No.
Description
1 B-10655- R
Crank Link Assembly
a) 02-4179
Link Spacer Bushing
b) 4010-01086-14
CapScrew,10-32x7/8,SH
c) 4700-00023-00
Washer,
5/8
o.d. x
13/64
i. d. x 16 gao
d) 4701-00004-00
Lockwasher, #10 split
e) 4410-01132-00
Nut, 10-32 ESNA
~ A-10656
Flipper Link Assembly
1.) 02-4219
Coil Plunger
2.) 20-9370-1
Spring Pin,
5/32
dia. x
7/16
3.) 01-7698
Flipper Link
g) B-10657-R
Flipper Crank Assembly , Right
1.) 01-8073-R
Flipper Crank, Right
2.) 17-1037
Crank Washer
3.) 4010-01066-18
Cap Screw , 10-32 x
1-1/8,
HCS
4.) 4410-01127-00
Nut, 10-32 Hex H. D.
5.) 4700-00107-00
Washer,
5/8
o.d. x
13/64
i. d. x 12 gao
6.) 4701-00004-00
Lockwasher, #10 split
7.) RM-23-06
Tubing, H. S. 1/4 DWP
2 C-9954-R
Flipper Base/Lane Change Assembly, R.
a) 06-14G
Insulating Blade
b) SW-1A-150
Lane Change Switch
c) 03-7568
Flipper Bushing
d) A-10821
Flipper Stop Assembly
e) 03-7811
End of Stroke (EO':» Switch
3 01-7695
Solenoid Bracket
4 10-376
Coil Plunger Spring
5 FL-23/600-30 /2600 Flipper Coil
6 23-6577
Bumper Plug
7 4010-01066-06
Cap Screw , 10-32 x
3/8,
AH
8 4710-00004-00
Lockwasher, #10 split
NOTES
1 Each Flipper Assembly is mounted below the playfield , In con -
junction with the plast ic flipper and shaft (20 ·9250) and flipper
rubber (23 ·6519) (on the upper side of fhe playf ield)
2 The tip of the EOS Switch must travel
,015 (. 010 ,
000 men ).
before the contacts fully open wifh the flipper in the actuated
position , The EOS Switch contacts must have a gap of ,062
(±
,015) inch , Any adjustment of the EOS Sw itch must be made at
a minimum distance of 25 inch from the switch body
3 The Lane Change Switch must have a gap of ,046 (~ ,015) Inch ,
when fully open
4 All moving elements of the assembly must operate freely without
any evidence of binding
5 Coil plunger spring must fit within the four lugs of the solenoid
bracket
6 For coil replacement,
remove solenoid bracket , (item 3) to ore -
vent screw damage
7 Use Locllte when reassembling flipper stop bracket screws
8 When using bumper plug on older fl ipper assembl ies , readjust
flipper position ,
9 Solid color grey (or blue) wire connects to the banded end of the
diode , mounted on the connector end of flipper co il (i tem 5) Wire
with trace color connects to the unbanded end of the diode
