Solenoids/ Flashers
Item Part No.
Description
1 AE-23-800-01 Trough Kicker (Outhole)
2 AE-23-800-03 Ball Shooter Lane Feeder
3 AE-23-800-03 Left Eject Hole
4 AE-23-800-03 Center Eject Hole
5A #63 Flashlamps Rear Playfield Flashers
5C AE-23-800-11 * Upper Left Kicker
6 AE-24-900-01*
Power Kicker (L. Outlane)
7 #63 Flashlamps LeftLightning Bolt
8 #63 Flashlamps Right Lightning Bolt
9 SM1-35-4000-DC Left Gate
10 SM1-35-4000-DC Right Gate
11 5580-09555-00 General IlluminationRelay
12 5580-09555-00 Solenoid Select Relay
13A AE-23-800-02 Credit Knocker
13C AE-24-900-02 Ramp Up
14 #63 Flashlamps Mid-Insert Board Flashers
14C SM-26-600-DC Ramp Down
15 #63 Flashlamps Bikes Flashers (Backbox)
16 404603-2**
Coin-Lockout Relay
17 AE-23-800-03 LeftKicker
18 AE-23-800-03 Right Kicker
19 AE-23-800-03 Top Jet Bumper
20 AE-23-800-03 Left Jet Bumper
21 AE-23-800-03 Right Jet Bumper
22 AE-23-800-03 Bottom Jet Bumper
FL
23/600-
Right Flipper
30/2600-50VDC
FL
23/600-
Left Flipper
30/2600-50VDC
* - with Relay Snubber
** - Coinco pIn
Rubber Parts
Item Part No.
Description
A 23-6300
5/16"
Ring
B 23-6301
3/4"
Ring
C 23-6302 1" Ring
D 23-6303
1-1/4"
Ring
..-.
E 23-6304
1-1/2"
Ring
F 23-6306
2-1/2"
Ring
G 23-6327 Ball Shooter Tip
H 23-6420 Grommet
I
23-6519-4 Red Ring
J 23-6535 Bumper
K 23-6552 Sleeving
L 23-6556 Sleeving
M 23-6577
5/8"
dia. Bumper
N 23-6579
3/4"
Tapered Bumper
