Backbox Parts Listing
Part No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
20-6542-TB
0-11032
A-7984
01-6645
0-10881-542
A-7985
01-8400
Not Used
5040-09051-00
5100-09418-00
C-9939
5733-10702-04
011197-542
01-8084
0-8345-541
B-10686
Description
'Cam Lock
PCB Plate Assembly
Upper Insert Board Hinge Assembly
Venting Screen
System 11 CPU, Road Kings
Lower Insert Board Hinge Assembly
Backglass Mounting Bracket
Capacitor, 30,000 J.!Fd., 25V
Bridge Rectifier, 100v, 35A.
Flipper" Power Supply
Fuse Holder
Background Music Board, Road Kings
Insert Stop Bracket
Power Supply Assembly
Knocker Assembly
