A-22960
Martian Mechanism Assembly
Item Part Number Description
1 01·15123
Martian Mechanism Main Bracket
2 20-8790-2
Nyliner Bearing
3 04-10910-7
Coil Centering Bracket
4 23-6420
Rubber Grommet
5 04-12595.2
Martian Plunger Assembly
6 10-135
Plunger Spring
7 03-7067
Coil Tubing
8 AE1·26-1500
Coil
9 04-10910-1
Coil Centering Bracket
10 4408-0111g.o1
Nut
8-32
ESNA-NTM
PJayfield shown for
reference only
Associated Parts:
Item Part Number Description
11 01·15124
Martian Retaining Bracket
12 23-6768
Martian Figurine
13 4008-01168-06
Machine Screw,
8-32
x
3/8"
2-25
