A-22992
Ball Catcher Assembly
Bend this end of spring up
90
degrees to aUowfor
installation into item 2.
Hem Partnumber Description
1 01-15193.2
Ball Catcher Main Bracket
2 01-15194
Backstop mounting Bracket
3 03-10008
Ball Catcher Backstop
4 02-5476
Ball Catcher Shaft
5 5647-12693-11
Sub Mini Micro Switch
6 01-8600
Insulator
7 01·8240
Plate
Nut2·56
8 20-8712-18
E-Ring
3/16"
Shaft
9 5070-09054-OQ
Diode
1N40041.0A
10 H-23019-8 2
Pin Cable
11 4008-01220-08
MS
8-32x
W'
Pin Hd
12 4002-01105-08
MS
2-56x
W'
P-PH-S
13 10-562.1
Ball Catcher Spring
14 4408-01119-01
Nut
8-32
ESNAlNTM
15 01-15204.2
Ball Catcher Anti Ball Trap Bracket
16 4008-01227-04
MS
8-32xW'
Pin Hd-SEMS
2-24
