A-23004-R-2 Flipper Assembly
I!!!!l
Part Number
Description
1 A-14877.1-R Flipper Bracket Assembly, Right
2 SW-1A-194
Switch Assembly
3 03-9878
Shock Deflector
4 4006-01003-08 MS 6-32 x Y2- P-PH-S
5 4008-01227-05 MS 8-32 x
5116"
Pin Hd-SEMS
6 01-14998
Switch Bracket
7 4010-01066-06 CS-10-31 x 318"SH
8 4701-00004-00
LW #10 Split
9 A-12390
Flipper Stop Bracket Assembly
10
a,
1-11629
Flipper Coil (Blue)
11 01-7695-1
Solenoid Bracket
12 4006-01003-04 MS 6-32 x
%"
P-PH-S
13 10-364
Spring
14 4006-01005-06 MS 6-32 x 318"P-PH
15 4406-01117-00 Nut 6-32 Hex
16 A-23000
Flipper Crank Unk Assembly
16a) A-22999
Flipper Crank Assembly
16a)1.01-11764-R Flipper Crank, Right
Item Part Number
168)2.01-9376
168)3.04-11222
168)4.4410-01127-00
168)5. 4700-00107-00
168)6.4701~
16b) A-15847
16c) 02-4676
16d) 4010-01086-14
16e) 4700-00023-00
161) 4701-00004-00
16g) 4410-01132-00
17 23-65n
18 03-7568
19 03-7066-5
Description
Bracket Retaining Spring
LockingStud
Nut 10-32 Hex Heavy Duty
FW .203 x .625 x .104
LW #10 Split
Ripper Unk Assembly
Bushing- Unk Spacer
CS 10-32 x
7/8-
SH
FW .203 x .625 x .059
lW #10 Split
Nut 10-32 ESNA
Bumper Plug
Ripper Bushing
Coil Tubing
Associated Parts: (Not Shown)
23-6695
Flipper Ring
20-1011O-S
Flipper Bat w/Shaft
Notes. •.
1. Each Ripper Assembly is mounted beneath the p/aylield, in conjunction with the Plastic Ripper
&
Shaft, and Ripper Rubber
on
the upper side of the
playlield.
2. With the flipper, in the non-activated position, the
EO.S.
Switch contacts must have a gap of.062
(:t.015)
inch. When flipper is activated switch must
close.
3. Any adjustment of the
EO.S.
switch must be made at
8
minimum distance of 0.25 inch from the switch body.
4. Longer blade of
EO.S.
switch must be made straight. Gap adjustment is done by adjusting shorter blade.
5. All moving elements of the assembly must operate freely without any evidence of binding.
6. Apply Loctite
TII
245
when reattaching screws
to
the Flipper Stop Assembly, the Solenoid Bracket, and the Flipper Bushing.
2-14
