A-19963-4
Ball Trough Assembly
J!!m
Part Number Description
Item Part Number Description
1
A-16809-2 Ball Trough Welded
12 4408-01119-00 Nut
8-32
ESN
Assembly
13 23-6702
Bumper Plug
2 01-11587
Ball Trough Front
14 A-18617-1
Trough IRED LED PCB
3 A-6306-2
Bell Armature Assembly
Assembly
4 AE1-26-1500 Coil
15 A-18618-1
Trough IRED Transistor
5 01-8-508-T Coil Retainer Bracket
PCB Assembly
6 03-7067-5
Coil Tubing
16 4006-01003-10 MS
6-32
x
5/8"
P-PH-S
7
11).135
Spring
17 23-6626
Rubber Grommet
8 23-6420
Rubber Grommet
18 4700-00004-00 FW
.146
x
.375
x
.032
9 03-8523
Insulator
19 02-4975
Bushing
10 01-11586
Coil Mounting Bracket
11 4008-01227-05 MS
8-32
x
5/16"
Pin-Hd-S
2-13
