SOLENOID TEST
The Solenoid test has three modes ~~Repeat, Stop, and Run. Only one solenoid should pulse at
a time. The system has detected a problem if more than one solenoid pulses, a solenoid comes
on and stays on, or no solenoids pulse during the Repeat and Run modes.
Repeat: The Repeat mode activates an individual solenoid. Press the Enter button to
start this test. The name of the first solenoid shows in the display and the corresponding
coil pulses. Press the Up or Down buttons to cycle through the solenoids, one at a time.
The same solenoid pulses until you press the Up or Down buttons to advance to the next
one. To return the Test menu, press the Escape button. To advance to the next test
mode, press the Enter button.
Stop: The Stop mode halts the Solenoid test. No solenoids should be active. To return
the Test menu, press the Escape button. To advance to the next test mode, press the
Enter button.
Run: The Run mode cycles through the solenoids automatically. The display shows the
name and number of the solenoid currently being pulsed. To return the Test menu, press
the Escape button. To return to the Repeat mode, press the Enter button.
SINGLE LAMP TEST
The Single Lamp test checks each lamp circuit individually. Press the Up or Down buttons to
scroll through this test. A lamp should ·Iight for each narne and number that is displayed. Any
other results indicate the system has detected a problem. To return to the Diagnostic menu,
press the Escape button.
LAMP ROW/COLUMN
This test allows individual rows and columns in the lamp matrix to be operated. This is useful for
troubleshooting wiring and driver problems.
Press the Up and Down buttons to cycles through the different rows and columns. To return to
the Diagnostic menu, press the Escape button.
ALL LAMPS TEST
This test causes all the controlled lamps to flash at the same time. Every controlled lamp should
flash. Any other results indicate the system has detected a problem. To return to the Diagnostic
menu, press the Escape button.
VIDEO TEST
FUSE CHECK
1-13
