5. Lift the playfield by the support bracket under the bottom arch. Rest the playfield on the top of the
cabinet as shown in Figure3. Close the coin door.
SKIS
(ATTACHED TO PLAYFIELD)
TRACK SLIDES
(ATTACHED TO CABINET)
STAY ARM
(ATTACHED TO CABINET)
Figure 3
6. Firmly grasp the playfield on the sides and slide it forward (toward you) along the bottom track slide
brackets. Do not unplug the cables on the bracket attached to the back of the playfield. Rotate the
front of the playfield down and set it on the floor as shown in Figures 4, 5, and 6.
Figure 4
FigureS
Figure 6
1-3
