8-12445-1
8all Shooter Rod Assembly
Item Part Number Description
1
2
3
4
5
6
7
8
Ball Shooter Knob
Shooter Rod Spring
FW, 25/64
x
5/8
x
16ga.
Shooter Housing
Shooter Sleeve
Power Spring
External Retainer Ring
Ball Shooter Tip
20-9253-7
10-149
4700-00051-00
21-6645-1
03-7357
10-148-1
20-8712-37
23-6327
Associated Assemblies:
9 01-3535
Rod Mounting Bracket
10 4010-01006-10 Mach. Screw: 10-32 x 5/8"
2-36
