#1192
MYSTIC
o
RUBBER PARTS
A R-521-1
B R-521-2
C R-521-3
o
D R-521
E R-521-4
F R-406-3
G R-243
PANEL TOP PARTS
1 Arch Rail
2 Rail Post (2)
3 Rail Post Cap (2)
4 BoUom Arch
5 Shooter Gauge
6 Ball Gate (L)
7 Ball Gate (R)
8 Screened >Plastics (Set)
9 Thumper Caps (3)
10 R.O. Wire & Bracket(2)
11 Iluide Rail (2)
12 Guide Wire
13'
Guide Wire
14 Guide Wire
15 Target Assy (Red)
16 Guide Wire
17 Guide Wire
18 Guide Wire
19 Guide Wire
2D Guide Wire
21 Guide Wire (2)
22 Guide Wire
23 Guide Wire
24 Buller Wire (2)
25 Ball Guide Assy
26 Spinner Gate Assy (L)
27 Spinner Gate Assy (R)
28 Drop Target Assy (2)
29 Drop Target Assy
30 Ball Gate & Wire Assy
31 Flipper & Shaft Assy (2)
32 R.O. Wire & Bracket (4)
~
5
1" Dia. (2)
1W'
Dia. (5)
2" Dia. (6)
%"
Dia. (2)
2W'
Dia. (2)
Flipper (2)
'/1."
Dia. (10)
M-1774
C-907
C-908
P-5871-75
P-6359-41
A-1475-12
A-1475-13
M-1330-171
A-3713-62
A-2806-1
C-935-5
M-121-98
M-121-46
M-121-99
AS-291H
M-121-101
M-121-32
M-121-100
M-121-102
M-121-47
M-121-18
M-121-43
M-121-44
M-121-53
A-3032-44
AS-2250-65
AS-2250-66
AS-2795-32
AS-2795-33
AS-2250-24
AS-2214-21
AS-2806
