8
C. FRONT DOOR GAME ADJUSTMENTS
High Score Feature Adjustments:
The game is designed to, award an extra ball (option) or a free game at each of three score
levels. The recommended levels are on the score card in the game.
Any levei from 10,000 to 990,000 can be set, as desired, It is also possible to reset or turn off (00)
any or all of the levels, if desired.
1. Push and release Self-Test button (See Figure III) at one second intervals approximately
six times or until identification number 01 appears on the 'Match/Ball in Play' display.
2. The number on the Player Score Displays is the score level." It can be increased, if
desired, by holding the credit button in. To decrease the score level, hold the credit button in
and depress and release the Self-Test button. Release the credit button when the desired
number appears. Note that the level changes 10,000 points at a time. If the number '00' is
left on the displays, the high score feature is eliminated for that level,
3. Repeat steps 1 and 2 for the Second and third score levels. The identification numbers
'02' and '03' on the Match/Ball
in Play display are for the second and third levels,
respectively.
High Score to Date and 1,000,000 Feature:
The game is designed to award free games when 'High Score to Date' is beat, or if the player
exceeds 1,000,000 points.
It is recommended that the level, which will build with play, be periodically reset to the factory
recommended level to encourage game play. The adjustment procedure is the same as for the
High Score Feature Adjustment, Steps 1 and 2. Continue pushing the Self-Test button until the
identification number '04' appears on the 'Match/Ball in Play' display and then do Step 2.
Any level from '00' to 990,000 can be set as described. It is to be noted that '00' does NOT tum
off the feature, as it does on High Score feature. The feature is turned off by positioning switches
asdiscussed underBack Box Game Adjustments:
'Canbe quickly set to '00' by pressing 833 on the MPU assembfvtnthe
back box orCoin Chute switch #3, (See Figure III).
