Dracula Test Continued ..•
Manual
Mode: This mode provides user control of the movement of the Dracula
mechanism. The Down button is used to move the mechanism to the left, and the Up
button is used to move the mechanism to the right.
Automatic Mode: This mode moves the mechanism automatically. The mechanism will
first return to its HOME position (position #1), and then move to positions 2, 3, 4, 5, 4, 3,
2, and back to HOME (position #1), with small pauses when a new position is reached.
The speed of the motor can be set by pressing the Enter button until the message "Test Mode:
Set Speed" appears on the second line of the display. To decrease the speed of the mechanism
during the test, press the Down button. To increase the speed of the mechanism during the test,
press the Up button.
This test is useful for clearing Dracula position switch errors that may appear in the test report. If
errors exist, they will be shown on the bottom line of the display. The error for a bad position
switch is cleared when the Dracula mechanism completes two consecutive successful moves to
the position.
During this test, the diagnostic test buttons inside the coin door act as follows:
Escape: This button returns to the previous menu.
Down: In Manual Mode, this button moves the Dracula mechanism to the left. When in Set
Speed Mode, this button decreases the speed of the mechanism.
Up: When in Manual Mode, this button moves the Dracula mechanism to the right. When in Set
Speed Mode, this button increases the speed of the mechanism.
Enter: This button is used to change the test modes.
EMPTY
BALLS
TEST
This test kicks out all balls loaded in troughs, lockups, poppers, and kick-outs until no balls
remain in those locations.
Note:
As
the trough kicks out balls, they will stack up in the shooter groove, which may require
manual clearing in order to allow further balls to be kicked out.
1-21
