INSTRUCTIONS FOR COIN TRIP SWITCH ADJUSTMENT
WIRE SHOULD BE IN CONTACT
WITH END Of CRESCENT
OPENING WHEN BLADE
ADJUSTMENT IS MADE.
NYLON SWITCH ACTUATOR
Long blade should be in contact with nylon switch actuator and have
0
maximum
overtravel of
1/32.
or
Using a gram gauge, tension of long blade should not exceed 10 grams.
SWITCH ADJUSTMENT
1. For small cains, such as dimes, adjust short blade so that the 'gap' between the
silver contacts is .045 to .055.
2. For larger (;, heavier coins the 'gop' should be .045 to .060.
3. Do not adjust 'gap' closer than .040.
POWER TRANSFORMER:
LOCATED ON MECHANISM PANEL, IT IS EQUIPPED WITH A SECONDARY
TAP.
IF YOUR GAME IS ON LOCATION WITH EXTREMELY LOW LINE VOLT-
AGE, REMOVE LEAD FROM LUG HARKED
24
VOLTS
AND
SOLDER TO ALTER-
NATE LUG MARKED
"HIGH". THIS WILL BOOST SECONDARY VOLTAGE
APPROXIMATELY
2-3
VOLTS.
LEG LEVELERS:
ARE
PROVIDED FOR TWO PURPOSES - 1ST
TO LEVEL GAME ON LOCATION,
2ND TO INCREASE
PITCH
FOR GAME PERCENTAGING. IF IT IS DESIRED
TO SPEED UP PLAY AND DECREASE SCORES, RAISE REAR LEG LEVELERS TO
INCREASE PITCH.
7
