SILICON BRIDGE RECTIFIER
·D.C.POSITIVE
THE FUNCTION OF THE RECTIFIER AND CAPACITOR IS TO CONVERT THE
ALTERNATING CURRENT (A.C.)
TO DIRECT CURRENT (D.C.),
SUPPLYING D.C.
TO THE BUMPERS, KICKERS ETC.
THE BRIDGE RECTIFIER SHOULD PRACTICALLY NEVER NEED REPLACING,
AS IT IS RATED WELL OVER THE VOLTAGE AND CURRENT REQUIREMENTS OF
THE COMPONETS IT SUPPLIES.
IF,
HOWEVER, THE
15
AMP
24
VOLT FUSE ON THE MECHANISM PANEL
OPENS,
IT COULD BE DUE TO A FAULTY RECTIFIER.
DISCONNECT THE A.C.
INPUT TO RECTIFIER,
REPLACE FUSE,
AND RECHECK.
IF THE 10 AMP FUSE LOCATED NEXT TO THE RECTIFIER OPENS, CHECK
ALL D.C.
COMPONETS I.E.
BUMPERS, KICKERS ETC. FOR SHORTS.
