SOUND MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM
DESIGNATION
PART
#
DESCRIPTION
1
A8 (see note 1)
AS-2888-3
PWB Module Complete-
2
J1
E-00715-0039
15 Pin Connector
3
J2
E-00715-0026
2 Pin Connector
4
TP1-TP5
P-05399
Test Clip
5
R1, R31
E-00105-0239
Resistor %W 5% 4.7K
6
R2, *R28
E-OO105-0281
Resistor %W 5% 15K
7
R3
E-00105-0263
Resistor %W 5% 47K
8
R4
E-00105-0257
Resistor %W 5% 3.9K
9
R5, R6, R9, R17, R19, R20,
E-00105-0185
Resistor %W 5% 10K
R23, R25, R26, R27, R30,
R37,R38
10
R10
E-00105-0248
Resistor %W 5% 150K
11
R11, R12, R14
E-00105-0285
Resistor %W 5% 1M
12
R13
E-00105-0284
Resistor %W 5% 470K
13
R15
E-00105-0279
Resistor %W 5% 360
14
R16
E-00105-0280
Resistor %W 5% 470
15
R18
E-00105-0278
Resistor %W 5% 2.7
16
R8
E-00105-0287
Resistor 1f4W5% 2.2K
17
R21
E-00105-0246
Resistor %W 5% 11OK
18
R22
E-00105-0286
Resistor 1W 4.7K
19
R24
E-001 05-021 0 Resistor 1f4W 5% 27K
20
R7
E-00105-0289
Resistor 1J4W 5% 1.1K
21
R35
E-00105-0228
Resistor %W 5% 9.1K
22
R36
E-00104-0096
Resistor 5W, 10% 750
23
RT2, RT3
E-00599-0015
Resist. Var. 91B, 10K
24
C1, C10
E-00586-0068
Cap., Disc. 100PF 1000V
25
C14, C15, C18
E-00586-0065
Cap., Disc .. 01MFD 500V
26
C7,C3
E-00586-0087
Cap., Disc .. 02MFD 500V
27
C19, C2, C5, C9, C16, C21 , E-00586-0088
Cap., Disc .. 05MFD 16V
*C22
28
C4, C12
E-00586-0089
Cap., Disc .. 1MFD 25V
29
C8, C11, C23
E-00586-0090
Cap., Elect. 1MFD 25V
30
C6
E-00586-0063
Cap., Elect. 2MFD 25V
31
C13
E-00586-0091
Cap., Elect. 100MFD 25V
32
C17
E-00586-0092
Cap., Elect. 100MFD 100V
33
Q1 (TIP 29)
E-00585-0043
Transistor NPN
34
Q2, Q3 (2N 3904)
E-00585-0031
Transistor NPN
35
CR 1, CR2 (1N 4148)
E-00587-0014
Diode
36
CR3 (1N 4004)
E-00587-0015
Diode
37
CR4 (1N 5243)
E-00598-0011
Diode, Zener
38
U1, U8 (MC 14049B)
E-00620-0033
Hex Inverter (J.C.)
39
U4, U5 (MC 14526B)
E-00620-0044
Programmable 4 Bit Counter
40
U2 (MC 14042B)
E-00620-0045
Quad. Latch
41
U7 (555)
E-00620-0004
Timer I.C.
42
U9 (LM 741)
E-00620-004 7 Operational Amp.
43
U10 {LM 380N)
E-00620-0048
Audio Amplifier
44
U11 (86 L93)
E-00620-0046
4 Bit Binary
45
C20
E-00586-0064
Cap., Disc .. 002
46
A8 (see note 2)
AS-2518-50
PWB Module Less Program
Memory U3
47
For Q1
E-00682-0008
Heatsink
NOTE 1: When ordering specify name of game.
NOTE 2: Order replacement memory chip U3 specifying name of game and part no. stamped on chip.
*Removed R28, C22 for AS-2888-4.
