AS-2518-49 RECTIFIER BOARD ASSEMBLY
@
§--.~;:r---4---t-- --'q==q::=t=~=+=:___+---~
-- ---"'.- ----ie 's
@
RECTIFIER BOARD ASSEMBLY
(Part of)
A2: POWER TRANSFORMER MODULE
COMPONENT PARTS LIST
- - ----_---- --- - - - -_-- -- - -_ -
REFERENCE
BALLY
ITEM DESIGNATION
PART
#
DESCRIPTION
~~-.-
-- - - - - - - _ - - - - -- -
P/OA2
AS-2518-49
Rectifier Board Assembly,
Complete
3
R1
E-00104-0092
Resistor, 10%, 600 Ohm, 10W
4
R2
E-00104-0091
Resistor, 25 Ohm, 5W
5
R3
E-00105-0226
Resistor, 5%, 100K Ohm, V4W
7
VR1
E-00623
Varistor
9
CR1, CR2, CR3, CR4
E-00587-0006
Diode (IN4004)
10
RP1, RP2
E-00602-0004
Rectifier Package (R712E,
VARO)
12
BR2, BR3
E-00602-0003
Bridge Rectifier (VJ248 VARO)
15
F2
E-00133-0028
Fuse,
3/
4A, 250V, 3AG, S.B.
16
F3
E-00133-0004
Fuse, 4A, 32V, 3AG
17
F4
E-00133-0005
Fuse, 5A, 32V, 3AG
18
F1,F5
E-00133-0027
Fuse, 20A, 32V, 3AG
19
F6
E-00133-0024
Fuse, 3A, 125V, 3AG, S.B.
20
FOR RP1, RP2
E-00682-0011
Heatsink, 6053B
21
TP 1, 2, 3, 4, 5
P-05399
Test Point
22
J1
E-00715-0033
9 Pin Wafer Connector
23
J2, J3
E-00715-0034
10 Pin Wafer Connector
24
F1, F5
E-00148-0022
Fuse Clips
25
F 2,3,4,6
E-00148-0021
Fuse Clips
28
