Assembly and Interconnection
With legs attached to cabinet and backbox positioned face-down on top of cabinet
with the opening facing the rear of the cabinet proceed as follows:
A. Pull five cables from backbox.
B. Reach into right side of pedestal hole, pull up ground strap, and push it
into backbox.
C. Remove ties securing cabinet and playfield cables to cabinet and pull up
these cables •
D. Interconnect five cables. They are size and color coded.
E. Insert line cord into notch in cabinet. DO NOT PLUG IN AT THIS TIME.
F. Push remote volume control clble, White-Red solenoid ground cable, and
transformer cable (terminated with four plugs) into backbox.
G. Lift up backbox and position on cabinet pedestal, engaging brackets for
support.
H. Remove shipping blocks from insert door.
..
I. Secure backbox to cabinet using two bolts and washers.
J. Connect ground braid and White-Red wires under wing nut and washer at bottom
of backbox.
K. Loosely position remote volume cable and Sound Board power cable in harness
and plug connector into 10J4 and 10J1, respectively.
L. Connect bridge rectifier connector 6P1/6J1, and plug remaining two
transformer connections into 3J1 and 3J9 on the Power Supply Board.
Inspection
A. Check all connectors in backbox for loose wire termination. Reseat any loose
wires by pushing in on the terminal.
B. Push on ail connectors attached to Master Display, CPU, Driver, and Sound
Boards, and check terminations on capacitor and bridge rectifier at the lower
right of the backbox.
C. Gently press on all the socketed IC packages on the CPU and Sound Boards.
D. Check that two fuses on the Sound Board, seven fuses on Power Supply Board,
and two fuses on Insert Board are secure. _
E. Push on the connector attached to Slave Display Boards.
F. Check that the line fuse in the bottom of the cabinet is secure.
-G. Check the transformer input connector in bottom of ca binet for loose wire
termination. Reseat any loose wires
by
pushing in on the termination.
H. Check the cabinet to coin door connector for lose wire termination. Reseat
any loose wires
by
pushing in on the termination.
