GAME CONTROL LOCATIONS
Cabinet Switches
The On-Off switch is located on the bottom of the cabinet near the right front leg.
The Start Button is the push-button to the left of the coin door on the cabinet exterior. Press the Start
button to begin a game, or during the diagnostic mode, to ask for HELP.
Coin Door Switches
The operator controls all game adjustments,
obtains bookkeeping information,
and diagnoses
problems, using only four push-button switches mounted on the inside of the coin door. The Coin
Door Switches have two modes of operation Normal Function and Test Function.
Normal Function
The Service Credits button puts credits on the game that are not included in any of the game
audits.
The Volume Up (+) button raises the sound level of the game. Press and hold the button until the
desired level is reached.
The Volume Down (-) button lowers the sound level of the game. Press and hold the button until
the desired level is reached. See Adjustment A.1 28 to shut sound OFF completely.
The *Begin Test button starts the Menu System Operation and changes the Coin Door Switches
from Normal Function to Test Function.
Test Function
The Escape button allows you to get out of a menu selection or return to the Attract Mode.
The!1Q (+) button allows you to cycle forward through the menu selections or adjustment choices.
The Down (-) button allows you to cycle backward through the menu selections or adjustment
choices.
The *Enter button allows you to get into a menu selection or lock in an adjustment choice .
...•...
-
_-
--
I
ESCAPE
ENTER
I
I
I
ITST MOllE FUNCTION
I
\
/
"-
/
Flipper Button
-,
"-
/
".
<,
Ball Launch
-
-
--
-
On-Olf Switch
"To reset High Score, hold down the Begin Test/Enter switch for
5
seconds while in
the Attract Mode.
