DOT MATRIX CONTROLLER BOARD
A-14039
J601
2
10
20
30
J602
1~;0
~20
J606
J]
,-----"J"",60",,4'rl
__jl ~
8
1 5
1
J601 Ribbon Cable, Data to/from J202; J903; J506
J602 Ribbon Cable, Data from J201
J603 Ribbon Cable ,Data to Dot Matrix Display Driver
J604-1 Orange, -125V to Dot Matrix Display Driver Pin 1
J604-2 Blue, -113V to Dot Matrix Display Driver Pin 2
J604-3 Key
J604-4 Black, Ground to Dot Matrix Display Driver Pin 4
J604-5 Black, Ground to Dot Matrix Display Driver Pin 5
J604-6 Gray, +5V to Dot Matrix Display Driver Pin 6
J604-7 Gray-Yellow, +12V to Dot Matrix Display Driver Pin 7
J604-8 Brown, +62 to Dot Matrix Display Driver Pin 8
C\I
;:!:
J603 ~
J605-1 White, 80VAC from transformer secondary
J605-2 White, 80VAC from transformer secondary
J605-3 Violet, 1OOVAC from transformer secondary
J605-4 Key
J605-5 Violet, 1OOVAC from transformer secondary
J606-1 Black, Ground loop from J606-3
J606-2 Key
J606-3 Black, Ground from J117-3
J606-4 Gray, +5V loop from J606-5
J606-5 Gray, +5V from J117-4
J606-6 Gray-Yellow, +12V loop from J606-7
J606-7 Gray-Yellow, +12V from J117-2
p,C.
Board Legend
J1-J6 Coin Door Interface Board
.Jtxx
Power Driller Board
J2xx
CPU Board
J5xx
Audio Board
J6xx
Dot Matrix Controller Board
J9xx
Fliptronlc II Board
Judge Dredd 3-32
