AUDIO BOARD

A-16917-20020

P1

P1 34-pin Ribbon Cable, Data to/from J601; J903; J202

J1-1 Black-Yellow, signal to speaker

J1-2 Not Used

J1-3 Key

J1-4 Black-Yellow, signal to speaker

J2-1 Black-Yellow, signal to speaker

J2-2 Key

J2-3 Not Used

J2-4 Black-Yellow, signal to speaker

J3-1 Gray, +5V from J114-3,4

J3-2 Key

J3-3 Gray, +5V from J114-3,4

J3-4 Black, Ground from J114-5,7

J3-5 Black, Ground from J114-5,7

J4-1 Gray-Green, 18VAC from transformer secondary

J4-2 Gray-Green, 18V AC loop from J4-1

J4-3 Key

J4-4 Gray, 18VAC from transformer secondary

J4-5 Gray, 18VAC loop from J4-4

J4-6 Gray-White, 18VAC from transformer secondary

J4-7 Gray-White, 18VAC loop from J4-6

SPEAKER WIRING DIAGRAM

[-~ ----:-1

m,~AurnoBOAR;--\

I

CABINET

I I

I

l

~

I

I

I

I

_______________

I

I

I

I

I

I

I

I

I

I

I

__________

J

I

I

I

I

I

I

I

I

I

I

I

SPEAKER PANEL

---------------
