Fliptronic II Board Assembly
A-15472-1
'I
0 0 0 0 0 0 0 0 0 • 0 0 01,3
J902
o
.
::;0
~ 0
o
o
o
o ••
~
o
J905
100.0001
6
,
m -
e
.
~
..
J'l
J904
U
~'-I--J9-03---'I~~
~
5
,
J901-1 White-Blue, SOVac from Power Drvr Brd J104-2
J901-2 White-Blue, SOVac loop from J901-1
J901-3 White-Blue, SOVac from Power Drvr Brd J104-1
J901-4 Key
J901-S White-Blue, SOVac loop from J901-3
J902-1
NlC
J902-2
NlC
J902-3
NlC
J902-4
NlC
J902-S
NlC
J902-6
NlC
J902-7 Orange-Blue, holding, lower left flipper coil
J902-8
NlC
J902-9 Yellow-Blue, power, lower left flipper coil
J902-10 Key
J902-11 Orange-Green, holding, lower right flipper coil
J902-12
N/C
J902-13 Yellow-Green, power, lower right flipper coil
J903, 34-pin ribbon cable, data to/from J202; J601; P1
J904-1 Gray, +SV from Power Driver Board J114-3, 4
J904-2 Gray-Green, +12V from Pwr Drvr Brd J114-1, 2
J904-3 Key
J904-4 Black, ground from Power Driver Brd J114-S, 7
J904-S Black ,ground from Power Driver Brd J114-S, 7
J906
J'l
looooni
u
6
,
J90S-1 Blue-Violet, F2 to right flipper opto J1-2
J90S-2 Blue-Gray, F4 to left flipper opto J1-2
J90S-3 Black-Yellow, F6 to right flipper opto J1-1 (not
used)
J90S-4 Key
J90S-5 Black-Blue, F8 to left flipper opto J1-1 (not used)
J90S-6 Orange, ground to left flipper opto J1-4
J906-1 Black-Green, F1 to lower right E.O.S. switch
J906-2 Key
J906-3 Black-Blue, F3 to lower left E.O.S. switch
J906-4 Black-Violet, FS to Visor Closed switch
J906-5 Black-Gray, F7 to Visor Open switch
J906-6 Orange, ground to E.O.S. switches
J907-1 Red-Green, +50V to lower right flipper coil
J907-2 Red-Green, +SOV loop from J907-1
J907-3 Key
J907 -4 Red-Blue, +SOV to lower left flipper coil
J907-S Red-Blue, +SOV loop from J907-4
J907-6
N/C
J907-7
NlC
J907-8
NlC
J907-9
NlC
3-27
---------------------------------------------------------------------------~('
