Dot Matrix Controller Board Assembly
A-14039.1
N ••.
J603
c::::::J
J60'
'~2 10
20
30
J602
'~ 210
20
:~
I
J604
I~
8
6 1 ~
J601,
34-pin ribbon cable, data to/from J202; J903; P1
J602,
26-pin ribbon cable, data to/from J201
J603,
14-pin ribbon cable, data to/from Dot Matrix DisplaylDriver
J604-1 Orange, -125V to DisplaylDriver pin 1
J604-2 Blue, -113V to Display/Driver pin 2
J604-3 Key
J604-4 Black, ground to Display/Driver pin 4
J604-5 Black, ground to DisplaylDriver pin 5
J604-6 Gray, +5V to DisplaylDriver pin 6
J604-7 Gray-YellOW,to DisplaylDriver pin 7
J604-8 Brown, +62V to DisplaylDriver pin 8
J605-1 White, 80Vac from transformer secondary
J605-2 White, 80Vac from transformer secondary
J605-3 Violet, 100Vacfrom transformer secondary
J605-4 Key
J605-5 Violet, 100Vacfrom transformer secondary
J606-1 Black, ground loop from J606-3
J606-2 Key
J606-3 Black, ground from Power Driver Board J117-3
J606-4 Gray, +5V loop from J606-5
J606-5 Gray, +5V from Power Driver Board J117-4
J606-6 Gray-Yellow, +12V loop form J606-7
J606-7 Gray-YellOW,+12V from Power Driver Board J117-2
3-26
