HIGH SPEED
GAME STATUS DISPLAYS (Continued)
The
HIGH SPEED Audit Table
lists the 44 items of the Audit Information portion of the
HIGH SPEED
Game
Status Displays. Presentation of the displays is similar to that for the Identification Information; however, the
SPEEDER 1 and SPEEDER 2 displays are combined as a descriptive phrase. In light type below the column
headings appear the respective backbox displays where the information appears. Because the SPEEDER 4 dis-
play contains information which depends on game play, only a few example entries are shown in the table. The
Credits display shows
Au
for all 44 audit items, so its entry is omitted from the tabular listing. Detection of erron-
eous data affecting any of the counters used in these audit items causes the message, ERROR, to be displayed
in the SPEEDER 3 display, during display of any audit item associated with that particular counter. (The program
does not analyze the cause of the error; it merely alerts the operator of the error's existence by the message.)
HIGH SPEED
Audit Table
Audit
Descriptive Phrases
Audit
Factor
1
Item
Value
(MATCH)
(SPEEDER 1 and 2 Displays)
(SPEEDER 4)
01
Left Coins (chute next to coin door hinge)
432
02
Center Coins
0
03
Right Coins
398
04
Paid Credits
830
05
Total Plays
06
Total Free (Tolal Free Plays)
07
Percent Free (% Free Plays)
08
Replay Awards
09
Percent Replay (% Replay Awards)
10
Special Awards
11
Percent Special (% Special Awards)
12
Match Awards
13
HSTD ( High Score 10 Dale) Credits
14
Percent HSTD (% HSTD Credits)
15
Extra Balls
16
Percent Ex. Ball (% Extra Balls)
17
Av. Ball Time (Average Time in Seconds)
18
Min. of Play (Minutes of Play)
19
Balls Played
20
Replay 1 Awards
21
Replay 2 Awards
22
Replay 3 Awards
23
Replay 4 Awards
24
1 Playr Games
25
2 Playr Games
26
3 Playr Games
27
4 Playr Games
28
Burn in Cycles
29
Yellow Lit (# of games when lit)
30
Red Lit (# of games when lit)
31
Mu~i Balls (# of Multi-Balls played)
32
Jackpot Won (# of times won)
33
Special Lit (# of times lit)
34
Freeway E.B. (Extra Ball) Lit (# of times Iii)
35
Ramp Shol (# of limes made with flipper)
36
Jackpot E.B. Lit (# of times lit after J'pot)
37
Kickbak Fired (# of times)
38
A-Mode Cycles (# of times Attraet Mode)
39
H. S. Reset Counter
40
Aut. Pet. Data 1
41
Aut. Pet. Data 2
42
Aut. Pet. Data 3
43
Aut. Pet. Data 4
44
Aut. Pet. Data 5
NOTE:
1. The numbers shown in this column for Items 1 through 4 are examples.
Entries for all items depend on the amount of play; thus, they will vary
from location to location.
Adjustment Information--Ad
At end of the Audit Information presentation, with the AUTO-UP switch in the Up position, the operator can press
the ADVANCE button to proceed to the Adjustment Information portion of the
HIGH SPEED
Game Status
Displays.
