GAME ADJUSTMENT PROCEDURE
(Continued)
SPECIAL PRESET ADJUSTMENTS CAUTION
Adjustments 53 through 66 are Special Preset Adjustments to enable the operator to perform the
setting of multiple adjustments at once. They permit the operator to: (1) modify a game for a spe-
cific area (special German coinage settings, for example, Ad 53 through 58); (2) change a group of
adjustments to conform with laws of certain localities (Ad 59 through 61); and (3) to change the
degree of difficulty of game play (Ad 62 through 66). A list of the preceding individual Adjustments
affected accompanies each of these Special
Preset Adjustments.
Whenever the operator
chooses to use any Special Preset Adjustment, the operator can later access any or all of the
individual Adjustments affected by that Special Adjustment for subsequent changes.
A similar technique is recommended in the event of error or uncertainty concerning any Special
Preset Adjustment, after the operator selects it: The operator can restore the factory setting of
each individual Adjustment, then select the desired Special Preset Adjustment, and then return to
any of the preceding individual adjustments to determine whether use of the Special Adjustment
has had the desired effect.
The Backbox displays for each Special Preset Adjustment indicate whether the operator has
selected it, by identifying the Adjustment in the SPEEDER 1 and 2 displays by name and the
selection choice of NO, meaning Not Selected (this is the Factory Settina), or YES, meaning
Selected, in the SPEEDER 4 display. Selection occurs by using the Credit button to choose YES
and then pressing ADVANCE.
53 Install German 1
The operator can modify the game pricing selection of Standard Setting 09 in the
PriCing Table
to permit
Credit Award play with 10 \,lames for 5 OM. Individual Adjustments are affected, as follows:
Ad.
~
t:l~w ~~l1iDg
Ad.
~
t:l~w ~~t1iDg
24 German 1 Coinage 10 Piays/5DM
07 Special Award
Credit
•
18 Hi Scr 1 Credits
03
08 Match Feature
On
19 Hi Scr 2 Credits
00
14 Backup Hi Scr 1
4,000,000
20 Hi Scr 3 Credits
00
15 Backup Hi Scr 2
3,500,000
21 Hi Scr 4 Credits
00
16 Backup Hi Scr 3
3,000,000
06 Replay Award
Credit
17 Backup Hi Scr 4
2,500,000
Note:
This Special Preset Adjustment is automatically installed, when the CPU Board jumper W7 is cut or
removed, AND the Factory SettiDg is requested.
54 Install German 2
The operator can modify the game pricing selection of Standard Setting 09 in the
Pricing Table
to permit
TickeVToken operatioD with 10 games for 5 OM. Individual Adjustments are affected, as follows:
Ad.
~
t:l!ilW~~t1iDg
Ad. Nrun.e
~!il~ ~~tljDg
24 German 1 Coinage 10 Piays/5DM
07 Special Award
Ball
18 Hi Scr 1 Credits
03
08 Match Feature
On
19 Hi Scr 2 Credits
00
14 Backup Hi Scr 1
4,000,000
20 Hi Scr 3 Credits
00
15 Backup Hi Scr 2
3,500,000
21 Hi Scr 4 Credits
00
16 Backup Hi Scr 3
3,000,000
06 Replay Award
Coil
17 Backup Hi Scr 4
2,500,000
55 Install German 3
The operator can modify the game pricing selection of Standard Setting 09 in the
Pricing Table
to permit
Keyset Mode operation with 10 games for 5 OM. Individual Adjustments are affected, as follows:
Ad. t::!mM
t:l!ilW~!ill1iD9
M
~
~ew ~ening
24 German 1 Coinage 10 Piays/5DM
15 Backup Hi Scr 2
00
•
18 Hi Scr 1 Credits
00
16 Backup Hi Scr 3
00
19 Hi Scr 2 Credits
00
17 Backup Hi Scr 4
00
20 Hi Scr 3 Credits
00
06 Replay Award
Audit
21 Hi Scr 4 Credits
00
07 Special Award
Score
14 Backup Hi Scr 1
00
08 Match Feature
Off
