V. GAME ADJUSTMENTS
Back Door Adjustments:
Each game has thirty~two switches located on A4, the MPU module, located in the back door, that allow
play to be customized to the location. See Figure III. Credits per coin, credit display, Pac~Men per game,
..
high game feature are selectable by means of the switches. The switches are contained in four-sixteen
'\.
lead packages numbered S1~8, S9~16, S, 7-24, and S25~32 for easy identification. The' 'ON" toggle position
-
:."
is marked on the assembly.
llIm
off power before making adjustments •
~
CREDITS/COIN ADJ USTMENTS
TOTAL
COIN CHUTE
SWITCHES
CREDITS CREDITS CREDITS
CREDITS
CREDITS CREDITS/COINS
(LEFT SIDE)
5 4
3 2
13 12 11 10
9
(RIGHT SIDE) OFF OFF OFF OFF OFF
1/1
Coin
OFF OFF OFF OFF ON 2/1 Coin
OFF OFF OFF ON OFF 3/1 Coin
OFF OFF OFF ON ON 4/1 Coin
OFF OFF ON OFF OFF 5/1 Coin
OFF OFF ON OFF ON 6/1 Coin
OFF OFF ON ON OFF 7/1 Coin
OFF OFF ON ON ON
8/1
Coin
OFF ON OFF OFF OFF
9/1
Coin
.0>
OFF ON OFF OFF ON 12/1 Coin
OFF ON OFF ON OFF 14/1 Coin
OfF ON OFF ON ON 1/2 Coins'
OFF ON ON OFF OFF 2/2 Coins'
OFF ON ON OFF ON
3/2
Coins'
OFF ON ON ON OFF 4/2 Coins'
OFF ON ON ON ON 5/2 Coins'
ON OFF OFF OFF OFF 6/2 Coins'
ON OFF OFF OFF ON 7/2 Coins'
ON OFF OFF ON OFF
812
Coins'
ON OFF OFF ON ON
9/2
Coins'
ON OFF ON OFF OFF 12/2 Coins'
ON OFF ON OFF ON 14/2 Coins'
ON OFF ON ON OFF 1/1 st Coin 2/2nd Coin
3/2
ON OFF ON ON ON Ollst Coin'
1/2nd Coin 1/3rd Coin
1/4th Coin
3/4
ON ON OF F OFF OFF 0/1 st Coin'
1/2nd Coin 0/3rd Coin"
2/4th Coin
3/4
ON ON OFF OFF ON l/1st Coin 1/2nd Coin 1/3rd Coin
2141h
Coin
5/4
ON ON OFF ON OFF I
II
st Coin
2/2nd
Coin 1/3rd Coin 3/4th Coin
7/4
ON ON OFF ON ON 1/1stCoin
2/2nd
Coin
2/3rd
Coin 2/4th Coin
7/4
ON ON ON OFF OFF
01
I st Coin'"
0/2nd Coin,u· , /3rd Coin
1/3
ON ON ON OFF ON O/lst Coin'* 0/2nd Coin"
0/3rd Coin**
1/4th
Coin
1/4
ON ON ON ON OFF
0/151
Coin*'*u a/2nd Coi n*"" 0/3rd Coin""
0/4th Coin""
1/5th Coin
1/5
ON ON ON ON ON
all
st Coin'·'
a/2nd Coin'"
1/3rd Coin 0/4th Coin*'*" 1/5th Coin
2/5
'No Credits until 2nd coin
IS
dropped.
"No Credits until 4th coin is dropped.
"·No Credits until 3rd coin is dropped.
•• •• No Credits until 5th corn is droipped.
