Lamp Boards
A-14529 4-Lamp Assembly
A-14530 5-Lamp Board
Part Number
DescrIption
Part Number
DescrIption
5768-12796-00
Lamp PCB
5768-12797-00
Lamp PCB
24-8767
Twist Lamp Socket
24-8767
Twist Lamp Socket
24-8768
Bulb #555, (6.3v, 0.25A.)
24-8768
Bulb #555, (6.3v, 0.25A.)
5070-09054-00
Diode, 1N4004, 1.0A.
5070-09054-00
Diode, 1N4004, 1.0A.
5791-10871-06
Connector, 6-pin Header Sq Post
5791-10871-07
Connector, 7-pin Header Sq Post
A-14531 6-Lamp Board
A-14532 5-Lamp Board
Part Number
DescrIption
Part Number
Description
5768-12798-00
Lamp PCB
5768-12799-00
Lamp PCB
24-8767
Twist Lamp Socket
24-8767
Twist Lamp Socket
24-8768
Bulb #555, (6.3v, 0.25A.)
24-8768
Bulb #555, (6.3v, 0.25A.)
5070-09054-00
Diode, 1N4004, 1.0A.
5070-09054-00
Diode, 1N4004, 1.0A.
5791-10871-08
Connector, 8-pin Header Sq Post
5791-10871-07
Connector,7-pin Flat Header
A-14533 s-tamp Board
C-12709 Playfield Lamp Target
Part Number
DescrIptIon
Part Number
DescrIption
5768-12800-00
Lamp PCB
5768-12409-00
Lamp PCB
24-8767
Twist Lamp Socket
24-8767
Twist Lamp Socket
24-8768
Bulb #555, (6.3v, 0.25A.)
24-8768
Bulb #555, (6.3v, 0.25A.)
5070-09054-00
Diode, 1N4oo4, 1.0A.
5070-09054-00
Diode, 1N4004, 1.0A.
5791-10871-07
Connector, 7-pin Header Sq Post
5791-10871-05
Connector, 5-pin Header Sq Post
A-14423-1 Playfield Relay Board
Part Number
DescrIptIon
5768-1 2243-00
5010-09534-00
5070-09054-00
5580-12782-00
5791-12273-02
5791-12273-07
Lamp PCB
Resistor, on
Diode, 1N4004, 1.0A.
Relay, 12vdc
Connector, 2-pin Header
Connector, 7-pin Header
GILLIGAN'S ISLAND 2-12
