Press the Enter button to activate the Test Menu, once the menu name is shown under the Main Menu.
Then, use the Up or Down button to cycle through the Test Menu selections. Press the Enter button to
activate the desired test when that test appears in the displays.
T.TEST
MENU
T.1 SwitchEdges
T.2 SwitchLevels
T.3 Single Switch
T.4 SolenoidTest
T.5 Flasher Test
T.G General IDumination
T.7 Sound
&
MusicTest
T.8 Single Lamps
T.9 All Lamps
T.10 Lamp
&
Flasher Tests
T.U DisplayTest
T.12 MotorTest
er
rint
·~ ·· .·· . 'I1
Switch Edges
For all switches, the number on the left indicates the column, the number on the right
indicates the row. Example- Switch 23 means 2nd column, 3rd row.
n to
enu.
1,
or
+ -_ _....
'1'0 test the Left and Right Flippers, press the Left or Right Flipper buttons during switch test. The flipper
name and switch number should show in the displays. Any other results indicate the system has
. .. • ••• •~ ~ . _ c . . ..
a problem with the flipper circuit.
To activate the Switch Edges Test, from the Test Menu, press the Enter button . The name and number of
each switch that is pressed is shown in the displays. If any other switch, or no switch at all is indicated,
the system has detected a problem with the switch circuit.
Press Escape to return to the Test Menu. Press the Up button to display the next test, (or the Down button to
._returnto a previous test). Press the Enter button to activate that test.
'I2
Switch Levels
Oncethe test name is shown under the Test Menu, press the Enter button. The name and number of each
switch that is activated is shown in the displays. This test automatically cycles through all switches
that are detected closed.
Press the Escape button to return to the Test Menu. Press the Up button to display the next test, (or the
Downbutton to return to a previous test). Press the Enter button to activate that test.
GILLIGAN'S ISLAND 1-2 7
