2
PRINTOlITS MENU
(optional board required)
Press the Enter button to activate the Printouts Menu, once the menu name is shown under the Main
Menu. Then, use the Up or Down button to cycle through the Printouts Menu selections. Press the Enter
button to activate the desired Printouts Group when that group appears in the displays.
21 EarningsData
P.2
MainAudits
P.8 StandardAudits
P.4 FeatureAudits
P.5 Score
Histograms
P.G Time
Histograms
P.7 Time-Stamps
P.8 AllData
The Printouts Menu is a combination of the other menus. This menu allows you to access and print
information in the available menu selections.
If no Printer is attached the the message "Waiting for Printer" appears in the displays. Note: Set the
print specification from the Adjustment Menu, A.5 Printer Adjustments.
Press the Escape button to return to the Printouts Menu. Then, either press the Up or Down button to
return to a previous Printouts Menu Group, or press the Escape button again to return to the Main Menu.
Once in the Main Menu press the Up button to advance to the next menu selection, the Test Menu, or
press the Down button to return to a previous Main Menu selection.
GILLIGAN'S ISLAND 1-26
