Jet Bumper Assemblies
B-9414
White Jet Bumper Assembly
Hem Part Number
Description
1 A-4754
2 03-6009-A5
3 03-6035-5
4 03-7443-5
5 10-7
6 A-11199
Bumper Ring Assembly
Bumper Base - White
Bumper Wafer - White
Bumper Body - White
Spring - Jet Bumper
Socket
&
Bulb
Associated Parts:
7 03-8254-13 Jet Bumper Cap - Clear
8 31-2-50003-1 Jet Cap Decal
•
•
B-9414-1
B-9414-3
•
Blue Jet Bumper Assembly
Red Jet Bumper Assembly
Hem Part Number
Description
Hem Part Number
Description
1 A-4754
Bumper Ring Assembly
1 A-4754
Bumper Ring Assembly
2
03-6009-AS Bumper Base - White
2 03-6009-AS Bumper Base - White
3 03-6035-1
Bumper Wafer - Blue
3 03-6035-4
Bumper Wafer - Red
4 03-7443-5
Bumper Body - White
4 03-7443-5
Bumper Body - White
5 10-7
Spring - Jet Bumper
5 10-7
Spring - Jet Bumper
"
6 A-11199
Socket
&
Bulb
6
A-11199
Socket
&
Bulb
Associated Parts:
Associated Parts:
7 03-8254-10 Jet Bumper Cap - Blue
7 03-8254-9
Jet Bumper Cap - Red
8 31-2-50003-1 Jet Cap Decal
8 31-2-50003-1 Jet Cap Decal
Jet Bumpers
2·16
