Left Flipper
Left Flipper Assembly
•
C-13174-L
Left Flipper Assembly
(Parts listed replace same items of C-13174-R)
C-13174-L-1
Upper Left Flipper Assembly
(Parts listed replace same items of C-13174-R)
•
Item Part Number
Description
1
B-13104-L
Flipper Base Assembly, L
21
B-10655-L
Crank Link Assembly, L
g)
B·10657-L
Flipper Crank Assembly
1.)
01-S073-L
Flipper Crank, Left
Item Part Number
Description
1
17
21
g)
1.)
B-13104-L
FL-11753
B-10655-L
B-10657-L
01-S073-L
Flipper Base Assembly, L
Flipper Coil (Yellow)
Crank Link Assembly, L
Flipper Crank Assembly
Flipper Crank, Left
Associated Pans:.
20-9250-6
23-6519-4
Flipper Arm on Shaft (Yellow)
Red Rubber Ring (Red)
Flipper Assembly Notes ...
1.
2.
3.
4.
5.
6.
7.
•
S.
Each Flipper Assembly on the Lower Playtield is mounted beneath the playfield, in conjunction with the
plastic Flipper Paddle and Shaft (20-9250-6) and Flipper Rubber (23-6519-4) on the upper side of the
playfield.
The tip of the EOS Switch must travel 0.150
(+
.010, - .000) inch, before the contacts fully open, with the
flipper in the actuated position. The EOS Switch contacts must have a gap of 0.062 (± .015) inch.
Adjustment of the EOS Switch must be made at a minimum distance of 0.25 inch from the switch body.
All moving elements of the assembly must operate freely, with no evidence of binding.
The large end of the Coil Plunger Spring (item 20) must fit within the four lugs of the Solenoid Bracket.
For coil replacement, remove the Solenoid Bracket (item 18) to prevent screw damage.
Use Loctite™ 242 when reattaching screws to the Flipper Stop Assemb\y, tne Solenoid Bracket, and the
Flipper Bushing.
When replacing their Bumper Plug (item 22) to restore proper flipper operation, readjust the flipper
paddle and shaft position.
Solid-color blue wire connects to the banded end of each diode, mounted on the connector end of the
Flipper Coil (item 17). Trace-color wire connects to the unbanded end of the diode.
