C-9638
Description
Ball Shooter Lane Feeder
•
Associated Parts
•
B-9362-R-3
B-7572-1
01-8-508-S
4006-01017-06
4406-01119-00
AE-26-1200
03-7066
Coil
&
Bracket Assembly
Bracket
&
Stop Assembly
Coil Retaining Bracket
Mach. Screw, 6-32 x 3/8
Nut, 6-32 ESN
Coil Assembly
Coil Tubing
Item Part Number
1 12-6227
2 A-8247
3 10-362
4 A-6949-L
5 A-8050-1
a) 02-3407-2
b) 20-8716-5
c) 03-8085
6 12-6227
7 4700-00030-00
8 4700-00103-00
9 A-8268
Hair Pin Clip
Eject Cam Assembly
Ejector Spring (Plain)
Spring Plate Assembly
Coil Plunger Assy, 2-1/8"
Coil Plunger, 2-1/8"
Roll Pin, 1/8 x 7/16
Armature Link
Hair Pin Clip
Flatwasher, 17/64 x112x 15ga.
Flatwasher, 17/64 x112x 28ga.
Mounting Bracket Assembly
A-8039-3 Outhole Kicker Assembly
Item Part Number
Description
A-6378
Mounting Plate Assembly
"
2 A-8335
Coil Plunger Assembly
a) 02-2364
Coil Plunger
b) 20-8716-5
Roll Pin, 1/8 x 7/16
0
c) 01-4251
Ball Return Link
3 03-7066
Coil Tubing
4 A-6889
Kicker Lever Assembly
0
5 A-8038
Coil Stop Assembly
6 AE-26-1200
Coil Assembly
7 03-7176-1
Striker Ring
8 10-101-4
Spring-Reset
9 20-8712-25
"E" Ring, 1/4" Shaft
10 4006-01003-03 ~ach. Screw, 6-32 x 3/16
•
2-13
Ball Shooter Lane
Feeder,
Out hole
Kicker
