Lamp Boards
•
B-12224 Single lamp Board
C-14086 lamp Board (n6_cn)
Part Number
Description
Part Number
Description
5768-12312-00
Lamp PCB
5768-12714-00
Lamp PCB
24-8767
Twist Lamp Socket
24-8767
Twist Lamp Socket
24-8768
Bulb #555, (6.3v, O.25A.)
24-8768
Bulb #555, (6.3v, 0.25A.)
5070-09054-00
Diode, lN4004, 1.0A.
5070-09054-00
Diode, 1N4004, 1.0A.
5791-10871-08
Connector, 8-pin Header Sq Post
A-14094 Clock lamp Board
C-13375 Clock Single lp Board
Part Number
Description
Part Number
Description
5768-12715-00
Lamp PCB
5768-12592-00
Lamp PCB
24-8767
Twist Lamp Socket
24-8803
Lamp Socket
24-8768
Bulb #555, (6.3v, 0.25A.)
24-8802
Bulb #906, (13v, 0.69A.)
5070-09054-00
Diode, 1N4004, 1.0A.
5791-10871-02
Connector, 2-pin Header Sq Post
5791-10871-12
Connector, 12-pin Header Sq Post
5010-09534-00
Resistor,
on
A-14115 Bill Board
A-14280 10-lamp Board
Part Number
Description
Part Number
Description
•
5768-12719-00
Lamp PCB
5768-12754-00
Lamp PCB
24-8804
Socket V-Wedge PCB
24-8767
Twist Lamp Socket
24-8768
Bulb #555, (6.3v, 0.25A.)
24-8768
Bulb #555, (6.3v, O.25A.)
5070-09054-00
Diode, 1N4004, 1.0A.
5070-09054-00
Diode, 1N4004, 1.0A.
5791-10871-08
Connector, 8-pin Header Sq Post
5791-10871-05
Connector, 5-pin Header Sq Post
5010-09534-00
Resistor,
on
•
Lamp Boards
2-12
