Table 10.
Game Operation and Adjustments
GAME OPERATION
ADJUSTMENTS
-
1. Play game manually to verify
No Control from Coin Door
Unable to Adjust Setting
problem.
Diagnostic Switches
I. Check for open Credit button
2. Review Section 2, Game Opera-
1. Check cabling for the switches in
switch
tion.
7PI, 7P2, and IP4.
2. Replace CPU Board.
3. Place in Diagnostics Test 04;
2. Check for stuck Credit button
review and change game adjust-
switch.
menta to that desired.
3. Replace CPU Board.
Table
11.
Inoperative or Blows Fuses
MACHINE INOPERATIVE
1. Remove plug from wall outlet and measure wall voltage.
2. With machine unplugged, check the line fuse, line cord, and ON/OFF switch with an Ohmmeter for continuity.
3. Check for any loose connections on line filter, ON/OFF switch.
4. Check that power connector to transformer is securely connected.
S. Check all fuses on power supply board.
6. Plug machine in, turn on and check voltage on power supply board fuses.
MACHINE BLOWS FUSE
Wall Fuse or Circuit Breaker Fuse
Machine Fuse
Individual Power Supply Fuse
I. Disconnect wall plug.
1. Check for correct fuse rating.
1. Disconnect load from portion of
2. Disconnect connector from line
2. Check varistor, line filter, line cord
the power supply that blows the
filter to transformer.
for shorts.
fuse by disconnecting the appropri-
3. Check line cord with Ohmmeter for
3. Disconnect connector from line
ate plug.
shorts.
filter to transformer and try
a. 3Fl (+100 VDC, -100 VDC)
4. Check varistor and line filter for
another fuse.
disconnect 3PS
shorts.
4. If fuse still blows, repeat steps 1-3.
b. 3F2 (+28 VUC) disconnect 3P4,
5. Plug cord in wall and see if wall
5. If fuse does not blow, disconnect
3P3
fuse still blows - if yes, dBconnect
3Pl and 3P2 plugs from the power
c. 3F3 (+18 VDC) disconnect 3P4
whatever else is on same wall plug
supply board and reconnect plug
d. 6Fl (6.3 VAC) disconnect 7Pl,
circuit and repeat steps 3 and 4
from line filter to transformer.
8P2
above.
6. If fuse blows, check transformer
e. 3FS (+5 VDC) disconnect 3P6
and both lamps and solenoid
2. If fuse still blows, replace Power
rectifiers for shorts.
Supply.
.
7. If fuse does not blow, plug in 3P2 3. If fuse does not blow, check for
and 3Pl then try again. If fuse now'
shorts in wiring, burned out
blows, disconnect 3P3, 3P4, 3P5,
solenoids, etc.
3P6, and try another fuse. If fuse
still blows replace Power Supply.
8. If fuse doesn't blow, hook up 3P3,
3P4, 3P5, and 3P6 one at a time. If
fuse blows when anyone is
plugged, look for burned out
solenoid, dead shorts, etc.
Table
12.
Losing Memory
GAME COMES UP IN TEST 04
GAME GOES TO DIAGNOSTICS FROM
WHEN TURNED ON
GAME OVER OR DURING PLAY
1. Check that the batteries are properly seated.
Perform procedures for intermittent operation provided
2. Turn game OFF and wait 30 seconds.
in Table 13.
3. Check battery voltage from the anode of ID17 to
ground. If less than 3.9 VDC, replace the batteries.
4. Check battery voltage from cathode of 1D17 to
ground. If less than 3.2 VDC, replace diode and
recheck voltage.
5. Replace CPU Board.
25
