Description
A..14422
Actuator Assembly
Item Part Number
1.
2.
3.
4.
5.
6.
7.
8.
9.
01·8111
A-14406
A-11146
A-6892
10·120
4701-00003-00
4700-00089-00
4008-01021-07
10·194
Ball Gate Coil Bracket
Coil Assembly
Armature Assembly
Frame & Eyelet Assembly
Spring
Lockwasher #8 Split
Flatwasher,
11/64
x
7116
x 16ga.
Mach. Screw, 8·32
x
7/16
P-RHBR
Extension Spring
0 ..11335 ..1
Ball Popper Assembly
Item Part Number
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
B-11631
A-11336
03·8053
20-9314-7
01-9794
AE-24-900
23-6420
10-135
4008-01017-04
03-7067
FISH TALES
2-23
Description
Bracket Assembly
Armature Assembly
Ball Popper Cap
Dowel Pin,
3/32
x
1/2"
Mounting Bracket
Coil Assembly
Rubber Grommet
Spring
Mach. Screw, #8-32 x
5/16
Coil Tubing
