Description
A.•14525
Kicker Bracket Assembly
Item Part Number
1. A-6306-2
2.
A-14526
3.
01-8-508-
T
4.
10-135
5.
23-6420
6.
AE-23-800
7.
03-7067-5
S. 4008-01017-04
9.
03-8523
Bell Armature Assembly
Mounting Bracket Assembly
Solenoid Bracket
Solenoid Spring
Rubber Grommet
Coil Assembly
Coil Tubing
Mach. Screw, #8-32 x
5/16
P-RH
Insulator
B-1 0686 •.1
Knocker Assembly
Item Part Number
1. A-5387
2.
8-7409-2
3.
AE-23-S00
4.
01-8-508-
T
5.
23-6420
6.
4008-01017-06
7.
H-11835
8.
03-7067-5
FISH TALES 2-22
Description
Coil Plunger Assembly
Mtg. 8racket Assembly
Coil Sub-Assembly
Coil Retaining Bracket
Rubber Grommet
Mach. Screw,
8132
x 3/8
Knocker Cable
Coil Tubing
..
