F. Check that line fuse in bottom of cabinet is secure.
G. Check transformer input connector in bottom of
cabinet for loose wire termination. Reseat any
loose wiresby pushing in on termination.
H. Check cabinet to coin door connector for loose
wire termination. Reseat any loose wires by push-
ing in on termination.
.Power Turn-On and Game
Setup
This machine MUSTBE PLUGGEDINTO A PROPERLY
GROUNDEDOUTLETto PREVENTSHOCKHAZARDand to
ensure PROPERGAMEOPERATION.DO NOTuse a
"che-
oter"
plug to defeat the ground pin on line cord, and
DO NOTcut off ground pin . Line voltage MUSTagree
with that specified on the back of "cabinet or serious
damage to machine could occur. For low-line appli-
cations (105 or 210V cc), refer to the power wiring
diagram.
A. With the coin door closed, plug game in and turn it
ON. Game should come on in Game Over mode as
indicated by Player 1 score reading zero, Game
Over lights lit, and High Score to Date alternating
with player scores.
B. If game comes on in the Diagnostic Mode (Credits
display showing 04, Ball in Play Display showing
00, and Player 1 display showing game identifica-
tion) turn game OFFand ON again.
1. If game now comes on in Game Over mode,
bookkeeping and game evaluation totals
have been reset to zero.
2. If game still comes on in Diagnostic Mode,
open coin door and turn game OFF,and ON
twice. This is an indication of batteries being
removed with power OFF or coming loose
during shipment. This has also resulted in fea-
tures reverting to factory settings. Any
changes from factory settings must be re-
entered using procedures provided in Instruc-
tion booklet.
C. If game stili comes on in Diagnostic Mode, CPU
board or memory-protect circuit may have failed.
D. Place three balls on playfield next to out hole.
E. Perform diagnostic tests and make any desired
chonqes to features as described in Instruction
booklet.
Location of Controls
ON-OFF
SWITCH-On bottom of cabinet in the area of
the right front leg as you face the game.
VOLUME
CONTROL-Accessible through coin door on
left cabinet wall.
DIAGNOSTIC
SWITCHES-Advance,
AUTO-UP/
MANUAL-DOWN, and high score reset switches are
located on back of COindoor. Refer to diagnostic and
adjustment procedures for operation .
MEMORY PROnCT
SWITCH-Must be open to clear
bookkeeping and make game adjustments. Located
on inside of coin door frame and automatically opens
when coin door opens.
CPU DIAGNOSTIC
SWITCH-Operates board self test
explained in diagnostic procedures. Located on left
edge of CPUboard.
SOUND BOARD DIAGNOSTIC
SWITCH-On top edge of
sound board and used to initiate sound board self test.
Referto diagnostic procedures.
SOUND SPEECH MIXER
CONTROL-Used in games with
speech to balance level of synthesised sound and
speech. Located on speech module.
7
