The following switch controls the memory of the A-D feature
Switch #24 A-D feature.
ON -Recalls
OFF-Resets
E.
CENTER BONUS FEATURE
The center bonus is advanced and scored by the left and right drop target bank. The starting position of the bonus is
controlled by the following switch.
Switch #15 Center Bonus Feature
ON -Starts with 15 lit
OFF - Starts with all otf.
F. MULTI-BALL FEATURE
To achieve multi-ball the player must first quality the saucers by hitting the top three targets. Then capture lor 2 of
the balls in the saucers. Hitting all three targets again release the ball(s).
There is a switch to control the top arrows.
Switch #23 Top Arrow Feature
ON -Recall
OFF-Reset
There is a switch to control the qualification of the saucers.
Switch #22 Saucer Qualifier
ON -Recall
OFF-Reset
Special is achieved only after both balls have been captured. Releasing balls qualifies special. Next time targets
are hit scores special.
G.
EXTRA BALL FEATURE
Extra ball is scored when all three center drop targets are down when lite is flashing.
H. PANIC POST FEATURE
Post is actuated with extra flipper button on right side of cabinet. Game starts with 5 credits, every time button is
actuated one (1) credit is removed. Two (2) credits are added to display each time center three drop targets are
knocked down.
"A-O" feature qualifies panic post feature to score 10,000 points at end of game for each credit
not used.
-
I.
SPECIAL REPLAY IX-BALL/NOVELTY MODES
Self test position 16 and 17 give the operator flexibility to award a replay ball or score (Novelty) when a
special is scoredl:combination of X/Ball, Novelty can be obtained through the following chart.
Self test positio
Set to ~
Set to "02"
Set to "01"
playfield X-balls and pecials
Awafi'
Award
Award
Doomsday Special
Replay
X-BALL
*
50,000
Odin-Wotan target Special
Replay
X-BALL
*
50,000
4 Drop target feature Special
Replay
X-BALL
*
50,000
Left or right out Special
Replay
X-BALL
*
50,000
Center drop target X-Ball
X-B~
X-BALL
**
25,000
Self test positiO~
Set t
"O;l
Set to "02"
Set to "01"
Awa
Award
Award
Scoring Thresholds
Replay
X-BALL
**
No Award
(0)
50,000 if same player shoot again is lit.
(•• ) 25,000
jf
same player shoot again
IS
lit.
4A
