AS-2518-61 SQUAWK
&
TALK
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM
DESIGNATION
PART
#
DESCRIPTION
-
51
C21
E w 586 w 68
Capacitor, Ceramic, 100pF
52
C15
E w 586 w 135
Capacitor, Electrolytic, 10 uF, 16V
53
C16,22
E w 586 w 73
Capacitor, Tantalum, 4.7 uF, 25V
54
C27
E w 586 w 136
Capacitor, Electrolytic, 1000 uF, 16V
55
C29
E w 586 w 124
Capacitor, Electrolytic, 470 uF, 6V
56
C3,4
E w 586 w 121
Capacitor, Ceramic, 27pF
57
C14
E w 586 w 123
Capacitor, Electrolytic, 4700 uF, 25V
58
C37,38
E w 586 w 147
Capacitor, Electrolytic, 330 uF, 50V
59
-'
60
J1
Ew736 w 15
15 Pin Wafer Connector (156)
61
J2
E-736-6
6 Pin Wafer Connector (156)
62
Used with VRl
E-682-11
Heatsink, 60538
63
Used with U18
E-682-8
Heatsink, 6030B
64
P-5399
Test-points
65
Sw.l
E-658 w 1
P.C.B. Switch
66
CR7,8,10
E-587 w 15
Diode (lN4004)
67
CR1, 5, 6, 9, 11
E-587w14
Diode (1N4H8)
68
Y1
E w 744 w 5
Crystal,3.579
69
LEDl
E-679
LED
70
01-2
E-585-31
Transistor, 2N3904
71
Used with U10
E-712-16
Socket I.C. 16 Pin
72
CR2-4
E w 587-22
Diode, VR332
73
Ul
E-620-125 Or 128
6808 or 6802
(See Note 1) Microprocessor
74
Used with Ul, 7,11
E-712-1
Socket I.C. 40 Pin
75
Used with UB, 9, 12
E-712-2B
Socket I.C. 28 Pin
76
Used with U18, VRl
LSPR-00632-1106
Screw
77
Used with VR1, U18
N-00632-2112
Nut
78
J3
E-766-20
Header, 20 Pin
-
79
R48
E-l05-312
2.4K,
114
W, 5%, Resistor
80
C36,43
E-586-63
2 uF, l6V, Capacitor
81
R69,70
E-599w16
Pot. 1K
82
Cl
E-586-148
47 uF Electrolytic Capacitor
83
R28,54
E-105-341
82K Resistor
84
Used with U18, VRl
M-1834
Thermal compound
85
Jumpers See Notes
-
30
