AS-2S18-61 SQUAWK
&
TALK
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM
DESIGNATION
PART
#
DESCRIPTION
1
PWB
P-2948-446a
M-645-577a
2
U10
E-620-171
AD5580AC
3
Used with U2 thru U6
E-712
24 Pin I.C. Socket
4
U7,11
E-620-29
6821 P.I.A.
5
U8
E-620-167
Tms 5200 Speech
7
U12
E-620-166
AY3-8912 Sound
8
U8
E-620-30
6810 RAM (See Note 1)
9
U16
E-620-33
4049 Hex Inverter
10
U13,14
E-620-126
LM3900
11
U15
E-620-169
74LS14 Schmidt Inverter
12
U17
E-620-168
74LS155
13
U18
E-620-127
TOA 2002 Power Amp
14
VRl
E-7l0
LM323, 5V Regulator
15
VR2
E-620-165
7905, -5V Regulator
16
Rl0, 19,29,42,50,63-67
71-78,55
E-105-185
Resistor, 1/4W, 10K
17
R2-5,8
E-105-238
Resistor, 1/4W, 5%, 3.3K
18
R20, 43
E-105-343
Resistor, 114W, 5%, 820K
19
R21,44
s-i
05-31 0
Resistor, 1/4W, 5%, 390K
20
R13,22,38,41,45
E-105-225
Resistor, 114W, 200K
21
R23,24,46, 61
E-105-226
Resistor,
%
W, 5%, lOOK
22
R30,53,56,80
E-l05-237
Resistor,1I4 W, 5%, 2K
23
R47
E-l05-151
Resistor, 1/4W, 5%, 2.7K
24
R25,26,27,32,49,59,60
E-l05-285
Resistor,
'/4
W, 5%, 1m
25
R33
E-l05-313
Resistor, % W,
5°/15,
91K
26
R37
E-105-245
Resistor, % W, 5%, 30K
27
R12,36, 57,58, 81
E-105-230
Resistor, 1/4W, 5%, 1K
28
R51
E-105-344
Resistor, 1/4W, 5%, 750K
29
R52
E-105-228
Resistor,
%
W, 5%, 9.1 K
30
R16
E-l05-203
Resistor, 1/4W, 5%, l30K
31
Rll
E-l05-248
Resistor, 1J4W, 5%, 150K
32
R15
E-l05-161
Resistor, 1/4W, 5%, 220K
33
R14
E-l05-346
Resistor, 114W, 5%, 1.8K
34
R17,18,39,40
E-l05-347
Resistor,1I4 W, 5%,91 OK
35
Rl
E-l05-243
Resistor, 1f4W, 5%, 27K
36
R68
E-l05-311
Resistor, 1J4W, 5%, 510 Ohm
37
R34
E-105-211
Resistor, 1/4W, 5%, 2.2 Ohm
38
R31
E-l05-303
Resistor, 1/4W, 5%, 220
Ohm
39
R79
E-l05-345
Resistor, 1/4W, 5%, 7.SK
40
R35
E-105-196
Resistor, 1J4W, 5%,1. Ohm
42
R7
E-l05-223
Resistor, 1/4W, 5%, 8.2K
43
C2,5-8, 10, 11,17,18,44 E-586-85
Capacitor, Ceramic, .01 uF 25V
44
C23,35
E-586-130
Capacitor, Ceramic, .47 uF 16V
45
R9
E-105-271
Resistor, 1/4W, 5%, 240K
46
R6
E-l05-342
Resistor, 1/2W, 470 Ohm
47
C19, 24, 25, 28, 31 , 34, 42 E-586-90
Capacitor, Electrolytic, 1
ufo
25V
48
C12,13,30,33,26,40,
39,41,46, 45
E-586-89
Capacitor, Ceramic, .1
ufo
25V
49
C9,20
E-586-83
Capacitor, Ceramic, 470pF, 50V
50
C32
E-586-120
Capacitor, Ceramic, 69pF
