The game is designed to make several tones and noises to announce power-up, game-up, etc. The
tones are intended to attract attentio~ame
and increase game usage. The tones are controlled
by pressing self test button until the 18 haws on the match/ball in play display. Now pulse replay
button to desired sound setting.
Setting "00"
Most switches associated chimes with
Setting
"or
Playfield switches associated chi es with background.
Setting "02"
Most scoring will have e effect without background.
Setting~
Most al~ng will have a noise effect with background.
GAME FEATURE OPTIONS:
Doomsday and outlane specials lite adjustment:
Liberal
Sw. 6 ON
Out lane special lites with doomsday special.
Conservative
Sw. 6 OFF
Outlane special lites after doomsday special is collected.
C and 0 rollover lane lite adjustment:
Liberal
Sw. 7 ON
Conservative
Sw. 7 OFF
Doomsday Special lite adjustment:
Liberal
Sw. 8 ON
Conservative
SW 8 OFF
Fireball bonus units limit adjustment:
Liberal
SW. 14 ON
Conservative
SW 14 OFF
Center feature 15,000 lite adjustments:
LibM~
SW150N
Conservative
e«
15 OFF
Game over attract adjustment:
SW 160N
SW160FF
Making Cor D lane puts both lites out.
Making C or D lane only puts that lane lite out.
Collect special after first 39,000.
Collect special after 2nd 39,000.
23 Units limit.
12 Units limit.
15,000 is on at start of game.
15,000 is not on at start of game.
Voice says "Fireball Awaits You:'
No Voice
Fireball2X, 3X, 4X, 5X bonus lite adjustment:
Liberal
SW 21 ON
Any lit bonus lite will come on for next ball.
Conservative
Sw. 21 OFF
Any lit bonus lite will not come on for next bali.
Odin and Wotan saucer qualified arrow lite adjustment:
Liberal
SW 22 ON
Any lit lites will come on for next ball.
Conservative
Sw. 22 OFF
Any lit lites will not come on for next ball.
Odin and Wotan 3 target arrow lite adjustment:
Liberal
sw. 23 ON
Any lit arrow will come on for next ball.
Conservative
SW 23 OFF
Any lit arrow will not come on for next ball.
A-8-C-O lane arrow lite adjustment:
Liberal
e«
24 ON
Conservative
Sw. 24 OFF
Any lites out will not come on for next ball.
Any lites out will come back on for next ball.
Number of games replays per game adjustment:
Liberal
Sw. 29 On
All replays earned will be collected.
Conservative
Sw. 29 OFF
Only 1 replay per player per game.
Collect Fireball bonus in outhole adjustment:
Liberal
SW 30 ON
Fireball bonus will be collected with regular bonus
Conservative
Sw. 30 OFF
Only regular bonus will be collected.
---
7
