Test/Diagnostic Procedures
ELVIRA
provides a series of diagnostic tests to aid the operator in determining
game condition (that Is. whether the game's features and highlights are operating
satisfactorily). These tests activate virtually all the electronic and
electromechanical devices comprising the game. so that the operator can readily
locate a malfunctioning device or simply verify that all devices are working properly.
In order. these tests deal with the music. the displays, the game sounds. the lamps.
the solenoids. and the switches.
In addttion to the diagnostic testing. a feature called the Auto Burn-in Mode is
avatlable. Activating this mode enables the operator to observe the game while all
of the diagnostic tests. except the switch test. occur. This can be very helpful in
locating 'intermittent' problems.
Activating either the entire test series or one of the individual tests requires use of
the Game Adjustment/ Diagnostic switches. Open the coin door for access to these
switches. To proceed to the Diagnostic Tests. the operator must simply switch the
game On. set the AUTO-UP/MANUAL-DOWNswitch to MANUAL-DOWN.and press
the ADVANCEbutton.
(~':; /A\
U1J "If 0
(Q)
[~_1
The System-l l B game program greatly aids the operator and service
personnel: At the beginning of the Test/Diagnostic Procedures (and also at
game Turn-On). the player score displays now Signal. with a message ("Press
ADVANCEfor Report") that at least one switch has Nor been actuated
during ball play for a lengthy period of time
(90
balls. or
-30
games).
Moreover. the Problem Reporting activity at the beginning of the Test/
Diagnostic Procedures. the display of problem switches now includes ALL
switches exhibiting problems. Refer to the text on Switch Tests for
additional information. To proceed with the Test/Diagnostic Procedures.
use AUTO-UP. and press ADVANCE.
Music Test
1. In the Music Test. observe that the player 1 and 2 displays show the
message. MUSICTESf. Switching to AUTO-UP. observe that the message
now reads MUSIC OFF. and that the player 3 score display shows 00 00.
Press the Credit button to select the desired music selection: 01 - 'Main
Theme' through 06 - 'Elvira's Theme' (the selections repeat). Adjust the
volume control for proper sound level for the game location.
2. Use the AUTO-UPposition.
1-34 Test/Diagnostic Procedures
