Pinball Game Assembly Instructions
Installation Procedure
1. Open the shipping container; remove all cartons. parts. and other items. and set
them aside.
2. Leg levelers and bolts are provided in the cashbox. Place cabinet on a support
and attach rear legs (after installing leg levellers). using leg bolts.
3. Attach the front legs (after installing leg levellers). using leg bolts. See Figure 3
for details.
I
J
~~
~
-
Leg
C-10843
Leg Leveller
Shaft
[e~
08·7377
•..•••.......Nut
~
4422·01117 ·00
-,
Leveller Foot Pad
Delail View· Leg Leveller
==:=
--
-_
" ~DegreeS
Approximate
Playfield Pitch
Angle:
7
Degrees
See
Detail
View
Figure 3. Pinball Assembly. Playfield Pitch Angle. and Leg Leveler Details.
/,A\,
LtD 'Tf" [I
(r~~ [rn
Ensure that the interconnecting cables are free to move (not kinked or
pinched). Be careful not to damage wires at any stage of the assembly
process.
4. Raise the hinged backbox upright and stabilize it into positron. Unlock the
backbox, and remove the backbox glass. storing it carefully to avoid scratches.
Remove the shipping block holding the Insert Board. This allows access to the bolt
holes used for securing the backbox uptight. Install the mounting bolts. split
lockwashers. and flat washers through the bottom holes of the backbox into the
threaded fasteners in the cabinet to secure the backbox. Close and latch the Insert
Board, and install the backbox glass, and lock the backbox.
Pinball Assembly Instructions 1-5
