Control Locations
Figure 2 shows the locations of the following switches, except for the last two (CPU
and Sound Diagnostic switches, which are shown in the Circuit Board Locations
Diagram, Figure 1).
THEON-OFF SWITCH
is on the bottom of the cabinet near the right front leg.
THEVOLUME CONTROL
is on the left inner wall of the cabinet on the tilt mechanisms
board. It is accessible
by
opening the coin box door.
THECREDIT ("STARTTHE PARTY") SWITCH
is a pushbutton to the left of the coin door
on the cabinet exterior.
GAME ADJUSTMENT/DIAGNOSTIC SWITCHES.
ELVIRA
allows the operator to control
all game adjustments, obtain bookkeeping information, and diagnose problems.
using only three switches mounted on the inside of the coin door, along with the
Credit button beside the coin door.
ADVANCE, AUTO-UP/MANUAL-DOWN,
and
HIGH-SCORE RESET
are the switches
located on the inside of the coin door. Refer to the text discussing Game Status
Displays and the Test/Diagnostic Procedures for details concerning button
operation.
THEMEMORY PROTECTSWITCH
is on the inside frame of the coin door. This interlock
Switch must be open to clear bookkeeping totals and to make game adjustments.
It
automatically opens. when the coin door opens.
On the previous page. the Circuit Board Locations Diagram shows the locations of
the two CPU Board switches (left edge of CPU Board, Backbox View).
THECPU DIAGNOSTIC SWITCH
(SW2) Is the lower switch (of
the two switches mounted on
the left edge of the CPU
Board) near a large, socketed
microprocessor chip. This
switch initiates the Memory
Chip Test explained in the
Test/Diagnostic Procedures.
THESOUND DIAGNOSTIC
SWITCH
(SW 1) is the upper
switch of the two mounted on
the left edge of the CPU
Board. This switch initiates
the Sound Section Test.
Refer to the Test/Diagnostic
Procedures.
1-4 Control Locations
/
/
On-Off SWitch
Figure 2. Control Locations
