REGISTER NO. 22 - BONUS CREDITS
This register is used in conjunction with the
Custom Coin Option Register #18. #19. # 20. and
#21. The number entered in register # 22
determines when a bonus credit will be delivered
while purchasing credits .
For example , entering a '4' into register #22 will
give the player an extra credit for every
4
credits
purchased prior to starting the game . This allows
the operator the ability to provide an incentive to
the player when the Custom Coin Option Registers
are used.
PLEASE NOTE: When register #17 is set to any
number other than '0' registers #18 through #22
will be ignored.
INCOME BOOKKEEPING REGISTERS
Specific registers have been assiqned to keep
track of coins dropped into the game.
REGISTER #
3
4
5
DISPLAYS
Coin Chute #1 (Left)
Coin Chute #2 (Center)
Coin Chute #3 (Right)
BALLS PER GAME; REGISTER 23
The number of balls per game can be set by
REGISTER 23. Any number entered from 1
through
5
will set the corresponding number of
balls per game.
MATCH FEATURE; REGISTER 29
When the Match Feature is ON, a random number
appears on the Match/Credit window and the word
Match is illuminated. If the number matches the
tens digit in a player's score, a free game is
awarded. The Match Feature creates an incentive
to play.
MATCH
ON
OFF
REGISTER 29
1
o
These registers may not be altered, but can be
RESET by entering '0'.
One additional meter is provided to record the total
number of Service Credits entered.
This
information is stored in register #9. The Service
Credits feature is provided to allow the operator to
test the game under normal conditions without
altering the Coin Chute or setti ng the game on free
play.
To enter Service Credits simply go to register#10-
Current Credits - and enter a number from 1
through 5. NOTE: This feature will not allow any
credits to be entered if the Current Credits register
is displaying 5 or greater. Then press the game
button on the keyboard and you're ready to start
playing by operating the Credit Button.
B. STANDARD GAME FEATURE
OPTIONS
MAXIMUM CREDITS; REGISTER 16
The maximum credits accepted by tne machine
limits the number of games that can be
accumulated by coining, by winning replays, or
both. The maximum number of credits is
selectable by means of setting REGISTER 16. Any
number entered between '1' and '40' will set the
corresponding credit limit.
CREDIT DISPLAY; REGISTER 30
CREDITS DISPLAYED
YES
NO
REGISTER 30
1
o
HIGH SCORE FEATURE; REGISTER 24
The game is designed to award an Extra Ball or
Free Game at each of the two or three score levels.
AWARD
REPLAY
EXTRA BALL
NOVELTY
NO AWARD
REGISTER 24
ENTER '3'
ENTER '2'
ENTER '1'
ENTER '0'
PLAYFIELD SPECIALS FEATURE; REGISTER 25
This feature allows the operator the flexibility to
award a REPLAY, EXTRA BALL, or SCORE
(NOVEL TV) when a special is scored.
AWARD
REPLAY
EXTRA BALL
NOVELTY
NO AWARD
REGISTER 25
ENTER '3'
ENTER '2'
ENTER '1'
ENTER '0'
1-9
