Unique Parts List
Part Number
Description
Part Number
Description
A-13100-1
Ball Gate Assembly
0-12313-2016
Backbox Interconnect Board
A-13767-2016
Backbox Assembly
0-13955
Speaker Panel Assembly
A-14073
Ball Gate Assembly
A-13571-2016
4-Bnk Drop Tgt
&
Decal Assy
A-14098
Big Shot. Kicker Assembly
H-12190-2016
Main Backbox Cable
H-13544-2016
Playfleld Switch Assembly
H-13545-2016
Playfield Lamp Cable
B-13840-11
Mix Master End Assembly
H-13546-2016
Playfield Solenoid Cable
B-13840-16
Mix Master End Assembly
H-13547-2016
. Insert Cable
B-13840-9
Mix Master
End
Assembly
H-13906
Mix Master Switch Assembly
B-13856
Ball Guide Assembly
H-13907
Mix Master Lamp Assembly
B-13860
Ball Guide Assembly
H-13908
Mix Master Flashlamp Assembly
B-13861
Ball Guide Assembly
H-13909
Magnet Lamp Cable
B-13862
Ball Guide Assembly
H-13910
Jackpot Lamp Cable
B-13922
Ball Guide Assembly
H-13986
Flasher 15
&
5C Cable
B-13935
Coil
&
Bracket Assembly
H-13989
Magnet Driver Cable
B-14010
Big Shot Assembly
H-13990
Motor Driver Cable
B-14033
Gift Gab, Light Assembly
H-13991
Left Ramp Cable
B-14034
Heart of R-N-R Assembly
H-13992
Flashlamp 8C Cable
B-14077-2
Standup Tgt. Assy (Green)
H-14088
Reflex Switch Cable
B-14077-4
Standup Tgt. Assy (ReG)
B-14077-6
Stand up Tgt. Assy (Yellow)
B-4834-K-2
Standup Switch Assembly
02-4436-14
F-F Spacer, 8-32 x 2"
02-4474
Playfield Spacer
C-13310-1
Motor EMI Assembly
C-13716
Ray Assembly
C-13794
Gear/Post Assembly
03-7960-2016-1
Playfield Mylar
C-13851
X-Ray Lamp Assembly
03-7960-2016-2
Playfield Mylar
C-13852
Dude Lamp Assembly
03-7960-2016-3
Playfield Mylar
C-13853
Magnetic Lamp Assembly
03-7960-2016-4
Playfield Mylar
C-13854
Reflex Lamp Assembly
03-8022-6
Spacer, 3/4"
C-13855
3-Lamp Playfield Assembly
03-8363-1
Locking Nut
C-13857
Ball Guide Assembly
03-8435
Gear, 115T (Clear)
C-13892
Triac Board Assembly
C-13911
Jumper Lamp Assembly
C-13954
Back Panel, 4-Lamp Assembly
C-14031
X-Ray Cap Assembly
2016-PL
Playfield Assembly
2016-PL-UP
Mini-Playfield Assembly
0-13643
Back Panel Assembly
0-13793
Spinner Assembly
31-1002-2016
Screened Playfield
0-13812
Main Ramp Assembly
31-1002A-2016
Screened Playfield
0-13839
Mix Master Shroud Assembly
31-1006-2016
Plastic Playfield Set
0-13858
Ball Guide Assembly
31-1008-2016 .
Screened Bottom Arch
0-13859
Ball Guide Assembly
31-1009-2016
Screened Shooter Gauge
0-11581-2016
Audio Board
31-1357-2016
Screened Backglass
0-11883-2016
CPU System 11B Assembly
31-1463-2016
4-Bnk Drop Target Decal
31-1592-2016
Glitter Decals
2·31
..Unlque
