A-14098
~~
I
I
I I
I I
6g
.•...
Big Shot Kicker Assembly
Jfl
@ .
I
.
I
I
1
Associated Parts
Item Part Number
Description
Item Part Number
Description
1 A-14099
Crank Assembly .
6
8-11203-R-1
Coil
&
Bracket Assy
2
A-14101
Kicker Mounting Bracket
a)
B-7572-1
Bracket Assy
3
A-8050-1
Plunger Assembly
b)
AE-26-1500
Coil Assy
a)
02-3407-2
Plunger Coil, 2-1/8"
c)
01-8-508-S
Coil Retainer
b)
03-8085
Armature Link
d)
03-7066
Coil Tubing
c)
20-8716-5
Roll Pin, 1/8 x 7/16
e)
4006-01 017-06 Mach. Screw, 6-32 x 3/8
4
12-6227
Hairpin Clip
f)
4406-01119-00
Nut, 6-32 ESN
5
4700-00030-00
Flatwasher, 17/64 x 1/2 x 15ga.
g)
10-128
Spring
8-14010 8ig Shot Assembly
8-14033 Gift Gab Assembly
Part Number
Description
Part Number
Description
01-9824
Mounting Bracket
A-8882-1
Socket & Bulb Assembly
01-9825
Mounting Plate
01-9840
Bracket
03-8447
Big Shot Character
4006-01027-04
Mach. Screw, 6-32 x 1/4
4406-01128-00
Nut, 6-32 KEPS
Big Shot Kicker
Gift Gab
2-30
